Examination tables with higher load capacity
2-section examination tables with a load capacity of up to 300 kg particularly suitable for obese patients.
Examination tables with 2-piece tabletop for obese patients
The 2-section examination tables with higher load-bearing capacity, which are indispensable in every doctor's practice, clinic and medical care centre, have been manufactured with larger tubular steel profile dimensions with thicker walls. Additional cross-bracing welded into the upholstery frame gives the examination tables the necessary stability and safety. For these reasons, these examination tables, which are particularly suitable for obese patients, can bear a load of 300 kg.
The examination tables for bariatric patients from AGA Sanitätsartikel are available in two lengths: 1,900 mm or 2,000 mm.
Features
The 2-section examination tables, which can bear loads of up to 300 kg, are impressive in terms of their stability, functionality and safety.
- They are available in a width of 800 mm.
- The stability and robustness is achieved by the gusset plates in the frame corners as well as the cross bracing between the table legs. In addition, larger tubular steel profiles with thicker walls were used and further cross-bracing was welded into the upholstered frame.
- The tubular steel frames are made of lacquered blank steel.
- The table legs are fitted with floor protectors (impact caps).
- The two upholstery segments (headrest and main surface) each have a thickness of 64 mm.
- The examination tables for heavier patients are available in a table height of 650 mm.
- They are available in two lengths: 1,900 mm and 2,000 mm.
- The headrest can be continuously adjusted up to +40°. It is locked in place by a handle with a clamping rod mechanism.
- The scope of delivery of the examination tables for heavier patients includes a paper roll holder bar. This is inserted between the table legs at the foot end.
Technical data
| Examination tables for bariatric patients | ||||||||
|---|---|---|---|---|---|---|---|---|
| Article number | XXL-1080/1900/PH | XXL-1080/2000/PH | ||||||
| Frame | Lacquered | |||||||
| Length Headrest/main surface | 1,900 mm | 2,000 mm 500 / 1,500 mm | ||||||
| Width | 800 mm | |||||||
| Height | 650 mm | |||||||
| Upholstery segments | 2 sections | |||||||
| Upholstery thickness | 64 mm | |||||||
| Headrest adjustment | +40° (clamping rods) | |||||||
| Belastbarkeit | 300 kg | |||||||
| Paper roll holder bar | ✓ | |||||||
The standard configuration includes:
- Table legs with floor protectors (impact caps).
- A paper roll holder bar between the table legs at the foot end, for 590 mm wide paper rolls.
We offer the coloured lacquer coating of the frames as standard in the following three shades (see frame colour selection card):
- light grey (RAL 7035)
- white aluminum (RAL 9006)
- pure white (RAL 9010).
The high quality finish has a glossy look. It is disinfectant resistant and easy to clean.
Other colours are of course also available. Please let us know the desired RAL colour so that we can find out the corresponding additional costs. Please note, however, that these products are then considered type variants with no right of return.
The artificial leather covers we use are characterized by their tear resistance, durability, longevity and their good cleaning properties as well as their resistance to disinfectants.
We use a (colour) selection from the synthetic leather covers VOWAled Pisa (Vowalon). The colour selection card can be found here.
In addition, we offer you the service of manufacturing the upholstery in other colours or from other synthetic leather manufacturers (type variant). After prior agreement, please send us the relevant references.
The black electrically conductive synthetic leather cover (with equipotential bonding socket on the frame) is available at an additional cost. It is already included in the price of the operating tables and multifunction tables.
Downloads
pdf | 2 MB
Image galleries
XXL-1080/1900/PH
XXL-1080/1900/PH
XXL-1080/1900/PH
XXL-1080/1900/PH
XXL-1080/1900/PH
XXL-1080/1900/PH
The photos show the examination table for obese patients, Article No.: XXL-1080/1900/PH, in the colours:
- Frame: pure white RAL 9010,
- Upholstery: blue.
XXL-1080/2000/PH
XXL-1080/2000/PH
XXL-1080/2000/PH
XXL-1080/2000/PH
XXL-1080/2000/PH
XXL-1080/2000/PH
The photos show the examination table for obese patients, Article No.: XXL-1080/2000/PH, in the colours:
- Frame: white aluminium RAL 9006,
- Upholstery: atoll.
Accessories & additional options
Article No. | Description |
|---|---|
GS-1710 | Face cutout in the headrest, oval, dimensions approx. 205 x 105 mm (L x W). Retrofitting is not possible. Upholstered insert for closing the face opening, oval, dimensions approx. 200 x 100 mm (L x W). See upholstery colours. |
HRM-14 | Semi-circular roll, foam filling, dimensions Ø 200 x 400 mm, sewn from synthetic leather, with zipper, see upholstery colours. |
HRM-14/Klett | Semi-circular roll, foam filling, dimensions Ø 200 x 400 mm, Velcro fastener (hook and loop straps), sewn from synthetic leather, with zipper, see upholstery colours. |
| KKM-16 | Head wedge, foam filling, dimensions 450 x 400 x 80 / 10 mm (L x W x H), sewn from synthetic leather, with zipper, see upholstery colours. |
| KVG | Headrest adjustment via gas pressure spring (instead of clamping rod mechanism), can be operated with just one hand, release button located directly on the headboard cushion. Retrofitting is not possible. |
| OPS-40/A OPS-60/A OPS-100/A OPS-140/A OPS-170/A | Standard rails (pair), approx. length 400 mm. Standard rails (pair), approx. length 600 mm. Standard rails (pair), approx. length 1,000 mm. Standard rails (pair), approx. length 1,400 mm. Standard rails (pair), approx. length 1,700 mm. Made of CrNi steel, dimensions approx. 25 x 10 mm, for mounting on the upholstery frame, approx. 13.5 mm away from the upholstery/upper frame with 2 (or 3) spacers each. Retrofitting is not possible. |
P-2080/XXL | Paper roll holder, chrome-plated, consisting of two brackets, two clamps and a paper roll holder bar (length 795 mm, Ø 20 x 1 mm), for mounting on the table legs. |
| PG-260 | Patient belt, dimensions 2,600 x 250 mm (L x W), for 800 mm wide tables. Sewn from synthetic leather, with Velcro fastener (hook and loops straps), see upholstery colours. |
RLM-20 | Knee roll, dimensions Ø 180 x 560 mm. Neck roll, dimensions Ø 140 x 400 mm. Round roll, foam filling, sewn from synthetic leather, with zipper, see upholstery colours. |
Product variants
As a manufacturer, we are able to adapt our products to your individual needs. Below, you will find examples of customer-specific requests we have implemented.
The delivery of examination tables for obese patients in other (lower) heights or the equipment with a different coloured synthetic leather cover is possible for an extra charge. We will be happy to quote you the surcharges on request.
